Product Specifications
- Total Thickness: 18m. (customized 5~25mm)
- Facing: Wood grain HPL sheet.
- Core Material: PVC board.
- Size: 1220x2440mm or customized.
- Density: 550kg/m³.
- Area Weight: 9.48kg/m².
- Application: Furniture.
Description
PVC board is a common furniture manufacturing material, usually used to make cabinets, door panels, etc.
It has the following characteristics:
- High strength: PVC board has high density, high rigidity, low deformation, stable structure and durability.
- Easy to process: PVC board has the same advantages as wood of being easy to cut and having high nail-holding power.
- Waterproof: PVC board is impermeable to water, so it has good waterproof properties, which makes it more reliable for use in humid environments.
- Environmentally Friendly: Compared to some other furniture materials, PVC sheet has a lower environmental impact because it can be recycled and reused, and relatively little waste is produced during the production process.
Our customized services:
- PVC boards of different densities are available.
- HPL surface texture can be customized: wood grain, solid, stone grain, etc.
- Custom sizes and CNC machining services are available.
Mechanical Properties
|
Project
|
Index
|
|
Tensile-strenghth(MPa)
|
≥12
|
|
Shao hardness D
|
≥55
|
|
Charpy notched impact strength
|
≥14
|
|
Elongation at break(%)
|
≥12
|
|
Heating size change ratio(%)
|
≥12
|
|
Vicat softening point(%)
|
±2.0
|
|
Softening point(℃)
|
≥73
|
|
Flexural strength(Mpa)
|
≥22
|
Specification Parameters
| Thickness | mm | 10 | 15 | 15 | 5 | 17 | 16 | 15 |
| Density | kg/m³ | 550 | 650 | 600 | 570 | 650 | 650 | 550 |
| Grammage | kg/m2 | 5.6 | 9.8 | 8.3 | 3.52 | 14.47 | 11.6 | 7.5 |
